Strong loading capacity: With a large bucket capacity and high lifting height, it can load more materials at once and has a high lifting force, making it easy to transport heavy goods and meet the needs of large-scale material loading, unloading, and transportation.
Intelligent management: equipped with LongGong intelligent management system, users can control various operational data and conditions of devices in real time through terminal devices such as mobile phones and computers, so as to scientifically and efficiently manage devices and improve device utilization.
Easy maintenance: The one-piece wingspan hood and large opening hood side door design make daily maintenance more convenient, and the maintenance space is spacious, which can effectively reduce maintenance costs and time.
| No. | Item | Code | Unit | |||
| 1.01 | Manufacturer | LONKING | ||||
| 1.02 | Model | LG16BE3 | LG18BE3 | LG20BE3 | ||
| 1.03 | Power type | Electric (AC) | ||||
| 1.04 | Rated capacity | Q | kg | 1600 | 1800 | 2000 |
| 1.05 | Load center | J | mm | 500 | 500 | 500 |
| 2.01 | STD Max height (with backrest) | mm | 4028 | 4028 | 4028 | |
| 2.02 | STD Max lifting height | h1 | mm | 3000 | 3000 | 3000 |
| 2.03 | Overhead guard height | h4 | mm | 2044 | 2044 | 2044 |
| 2.04 | Overall length (with fork) | L1 | mm | 2875 | 2875 | 3133 |
| 2.05 | Wheelbase | L2 | mm | 1400 | 1400 | 1508 |
| 2.06 | Front overhang | L3 | mm | 365 | 365 | 365 |
| 2.07 | Rear overhang | L4 | mm | 190 | 190 | 190 |
| 2.08 | Min.ground clearance (Frame/Mast) | m1/m2 | mm | 85/105 | 85/105 | 85/105 |
| 2.09 | Overall width | W1 | mm | 1060 | 1060 | 1120 |
| 2.1 | Adjusting range of fork (outside) | mm | 200-970 | 200-970 | 200-970 | |
| 2.11 | STD Fork size (L5*W*T) | mm | 920×100×35 | 1070×120×40 | ||
| 2.12 | Front wheel tread | S | mm | 910 | 910 | 920 |
| 2.13 | Rear wheel tread | P | mm | 175 | 175 | 175 |
| 2.14 | Min.turning radius | R1 | mm | 1590 | 1590 | 1698 |
| 2.15 | Min aisle width for pallet 1000×1200,crossways | mm | 3280 | 3280 | 3380 | |
| 2.16 | Min aisle width for pallet 800×1200,lengthways | mm | 3400 | 3400 | 3508 | |
| 3.01 | Wheels number, front/rear (X=driven wheels) | X=2/1 | ||||
| 3.02 | Tires type | Solid Tires | ||||
| 3.03 | Tires size, front | 18×7-8 | 18×7-8 | 200/50-10 | ||
| 3.04 | Tires size, rear | 15×4.5-8 | 15×4.5-8 | 15×4.5-8 | ||
| 4.01 | Max.traveling speed, loaded/unloaded | km/h | 13.5/13.5 | 13.5/13.5 | 13/15 | |
| 4.02 | Max.lifting speed, loaded/unloaded | mm/s | 300/440 | 300/440 | 300/440 | |
| 4.03 | Lowering speed, loaded/unloaded | mm/s | Loaded≤600/Unloaded≥300 | |||
| 4.04 | Max.gradient, loaded/unloaded | % | 20/20 | 20/20 | 20/20 | |
| 4.05 | STD operating weight (with oil & water) | kg | 3180 | 3290 | 3380 | |
| 4.06 | Axles loading,front/rear (loaded) | kg | 4300/620 | 4570/605 | 4920/545 | |
| 4.07 | Axles loading,front/rear (unloaded) | kg | 1600/1600 | 1600/1710 | 1710/1690 | |
| 4.08 | Drive motor | kw | 5.4×2 | 5.4×2 | 5.4×2 | |
| 4.09 | Lift motor | kw | 11 | 11 | 11 | |
| 4.1 | Controller | inmotion | inmotion | inmotion | ||
| 4.11 | Battery votage/capacity | V/Ah | 48/600 | 48/600 | 48/600 | |
