Strong loading capacity: With a large bucket capacity and high lifting height, it can load more materials at once and has a high lifting force, making it easy to transport heavy goods and meet the needs of large-scale material loading, unloading, and transportation.
Intelligent management: equipped with LongGong intelligent management system, users can control various operational data and conditions of devices in real time through terminal devices such as mobile phones and computers, so as to scientifically and efficiently manage devices and improve device utilization.
Easy maintenance: The one-piece wingspan hood and large opening hood side door design make daily maintenance more convenient, and the maintenance space is spacious, which can effectively reduce maintenance costs and time.
| Name | Data | |
| Basic | Operating Weight | 3000 kg |
| Weight Burden on Front Drum | 1500 kg | |
| Weight Burden on Rear Wheel | 1500 kg | |
| Min Ground Clearance(h) | 252 | |
| Wheelbase (L1) | 2000 | |
| Grade Ability | 30% | |
| L×W1×H (mm) | 2750×1350×2760 | |
| Engine | Manufacturer | QUAN CHAI |
| Model | 3B2-38C31 | |
| Displacement | 1.91L | |
| Fuel consumption | 7.7L | |
| Rated Power | 28 kW | |
| Rated Speed | 2600 rpm | |
| Emissions Standard | Nation Ⅲ | |
| Drive Train | Drive Type | Hydrostatic Drive |
| Travel Speed Forward | 0-8 km/h | |
| Travel Speed Reverse | 0-8 km/h | |
| Tire Type | — | |
| Min.Turning Radius | 4000 mm | |
| Steering Angle | 33 ° | |
| Swing Angle | ±10 ° | |
| Vibration System | Width of Drum (W2) | 1200 mm |
| Diameter of Drum | 710 mm | |
| Rim Thickness of Drum | 12 mm | |
| Static Linear Load | 125/125 N/cm | |
| Vibration Type | Open-loop Hydraulic Vibration | |
| Centrifugal Force | 30 kN | |
| Vibration Frequency | 50 Hz | |
| Nominal Amplitude | 0.5 mm | |
| Brake System | Service Brake | Hydraulic Lock Front and Rear Brake |
| Parking Brake | Oil Cut Front and Rear Wheel Brake | |
| Electric | Voltage | 12 V |
| Capacity | 120×2 Ah | |
| Service Refill | Fuel Tank Capacity | 50 L |
| Hydraulic Tank Capacity | 75 L |
