Strong loading capacity: With a large bucket capacity and high lifting height, it can load more materials at once and has a high lifting force, making it easy to transport heavy goods and meet the needs of large-scale material loading, unloading, and transportation.
Intelligent management: equipped with LongGong intelligent management system, users can control various operational data and conditions of devices in real time through terminal devices such as mobile phones and computers, so as to scientifically and efficiently manage devices and improve device utilization.
Easy maintenance: The one-piece wingspan hood and large opening hood side door design make daily maintenance more convenient, and the maintenance space is spacious, which can effectively reduce maintenance costs and time.
| Basic | Operating Weight | 3500kg |
| Rated Payload | 1230kg | |
| Bucket Capacity | 0.54m³ | |
| Tipping Load | 2460kg | |
| Breakout Force | 28.06kN | |
| Traction Force | 25.9kN | |
| L×W×H | 3460×1820×2000 | |
| Engine | Engine Model | A498BZG |
| Rated Power | 55kW/2500rpm | |
| Displacement | 3.168L | |
| Fuel consumption | 15.9L | |
| Stroke | 98mm | |
| Bore | 105mm | |
| Emission Standard | NationⅡ | |
| Hydraulic system | Hydraulic Flow – Standard | 91L/min·2500rpm |
| Type | Mechanical Servo | |
| Hydraulic Pressure– Standard | 21MPa | |
| Hydraulic Flow – High Flow | 135L/min·2600rpm | |
| Loader Hydraulic Pressure | 19 Mpa | |
| Drive train | Travel Speed -F&R | 11.8km/h |
| Tyre | 12-16.5 NHS | |
| Electric | Voltage(V) | 12 V |
| Capacity(Ah) | 120 Ah | |
| Service refill capacity | Chain Box, Each Side | 9L |
| Cooling System | 12L | |
| Engine Crankcase | 9L | |
| Fuel Tank | 91L | |
| Hydraulic Tank | 65L |
